What Happens When You `kubectl apply -f network-policy.yaml`?.

There's a famous interview question floating around the internet: What happens when you type www.google.com into your browser and hit enter?¹ If you've never seen the answer written out, do yourself a favour and read it; it's a masterclass in how much sits underneath an action that feels instantaneous.

There's a sibling question that I like even more, that is shorter on the wire but just as deep in the kernel: What happens when you run ls in your terminal?

I've spent the last few weeks elbow-deep with network policies in kubernetes, and one nasty bug that I hit was an orphan BPF pin files leak in aws-network-policy-agent on our EKS clusters at work. While I had the layers fresh in my head, it felt like a good moment to sit down and write the Kubernetes-flavoured version of the same question: What happens when you kubectl apply -f network-policy.yaml?

A NetworkPolicy is one of those Kubernetes objects that feels like it should be simple. You write a YAML, you say "deny everything except this", you press return, and packets start getting dropped. But that one-liner hides at least six distinct layers — control plane, controller, CRD, node agent, eBPF verifier, and the actual kernel hook that fires on a packet, and any one of them can fail silently. The fun is in walking down the stack.

A caveat before I start: this walkthrough is anchored on EKS running the AWS VPC CNI plus aws-network-policy-agent (NPA), because that's the dataplane I've been living inside. The shape of the story is the same on Calico and Cilium; the dataplane is wildly different. I'll come back to that near the end.

The policy we'll trace through the stack is the most boring one I could come up with on purpose:

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: api-allow-from-frontend
  namespace: prod
spec:
  podSelector:
    matchLabels:
      app: api
  policyTypes: ["Ingress"]
  ingress:
    - from:
        - podSelector:
            matchLabels:
              app: frontend
      ports:
        - protocol: TCP
          port: 8080

In English: pods labelled app=api in prod only accept TCP/8080 from pods labelled app=frontend.

Now let's watch what the cluster actually does with that.

Stage 1: kubectl apply, the easy bit

kubectl is, almost embarrassingly, just a fancy HTTP client. When you run

❯ kubectl apply -f network-policy.yaml

a few things happen on your laptop before a single byte leaves it:

1. kubectl parses the YAML and converts it to JSON — Kubernetes' API is actually JSON-over-HTTP; YAML is an ergonomic shim for humans.

2. It consults its discovery cache (under ~/.kube/cache) to figure out which API group/version owns NetworkPolicy — networking.k8s.io/v1 — and therefore which REST path to use: POST /apis/networking.k8s.io/v1/namespaces/prod/networkpolicies.

3. It computes the three-way diff between the file you applied, the last-applied annotation, and the live object (if it exists). This is the reason apply is idempotent and create isn't.

4. It opens a TLS connection to the apiserver, presents the client cert in your kubeconfig, and sends the request.

The apiserver does a lot more than people give it credit for. The request goes through, in order:

• Authentication: your client cert, OIDC token, or webhook auth tells the apiserver who you are.

• Authorization: RBAC checks whether you are allowed to create networkpolicies in prod. (If you're using ABAC or webhook authz, those fire here too. Almost no one is.)

• Admission: both mutating and validating admission webhooks. This is where Pod Security Standards, OPA Gatekeeper, Kyverno, and a long tail of in-house policy engines get a chance to rewrite or reject the object.

• Schema validation: the object is checked against the OpenAPI schema for networking.k8s.io/v1.NetworkPolicy. Typo podSelector as podSelecter and this is where you find out.

• Storage: the apiserver writes the object to etcd via a transactional Txn that includes a resource-version check. Only after this commit does the object exist in any meaningful sense.

The instant etcd commits, the apiserver's watch cache fans the new NetworkPolicy out to every controller and agent that has an open watch on that resource. If you want to see this happen in real time, run kubectl get networkpolicy -A -w in a second terminal before you apply, the watch event lands within a few milliseconds.

So far we have a row in etcd. The cluster's behaviour hasn't changed. Not a single packet has been dropped or permitted differently because of what we just did. A NetworkPolicy on its own is inert, it's a declaration of intent. Something has to be listening.

Stage 2: Two controllers wake up

In the AWS VPC CNI world, two things care that we just wrote a NetworkPolicy:

1. The network-policy controller (amazon-network-policy-controller-k8s), which on EKS runs inside the managed control plane.

2. The per-node aws-network-policy-agent (NPA), running as a sidecar in the aws-node DaemonSet pod on every worker.

The controller's job is resolution. The selectors in your YAML (app=api, app=frontend) are not the truth — they're a query over the truth, and the truth lives in the Pod and Namespace objects in etcd. The controller has to translate "all pods labelled app=api in prod" into a concrete list of pods, on specific nodes, with specific IPs, right now. And it has to keep doing that, forever, because:

• A pod can be labelled app=api today and app=archive tomorrow.
• A new pod can be scheduled with app=frontend two seconds from now.
• A namespace can get a new label that changes whether a namespaceSelector matches.
• A pod can be rescheduled to a different node and pick up a different IP.

This is the part where I think a lot of NetworkPolicy mental models start to fall apart, people imagine a static "firewall rule" being installed once, when in reality the controller is in a continuous reconciliation loop. The selector app=frontend is "labels at this moment", not "labels at the time you applied".

What the controller produces is a PolicyEndpoint custom resource (cluster-scoped variant: ClusterPolicyEndpoint). Roughly one per (NetworkPolicy × node-with-matching-pods). Crucially, a PolicyEndpoint has no selectors in it, only fully-resolved pod IPs, CIDR ranges, ports, and protocols. All the dynamic resolution work has been done; the result is the boring, concrete, byte-pushable version of your intent.

You can see them with kubectl get policyendpoint -A. If you've never looked, do, they're the most concrete answer to "what does my NetworkPolicy actually mean right now?" you're going to get.

A reasonable question: why a CRD as the contract between the controller and the agent? Why not a direct gRPC? The convincing answer I could conclude is that you get a lot for free, Kubernetes' API gives you ordering, retries, audit, RBAC, field-selectors, watches, and kubectl get as a debugging tool, and you pay for it with a small amount of latency and a CRD type to maintain. It's a good trade.

Each NPA pod watches PolicyEndpoint with a field selector pinned to its own node, so it only sees the resolved policies for the pods it actually hosts. That sharding is the only reason this design scales.

Stage 3: The agent translates pods into eBPF

Now we're on the worker node. NPA is running in the aws-node DaemonSet pod, in the host network namespace. It does two things:

1. Watches PolicyEndpoint on the apiserver (Stage 2's output).
2. Listens on a tiny gRPC server at 127.0.0.1:50052, which the CNI plugin calls during pod ADD and DEL to say "this pod just appeared, here's its namespace and veth" or "this pod is gone".

For each pod that has at least one policy applied to it, NPA computes a podIdentifier. The formula is, and I had to read this code very carefully before I trusted it, roughly:

1. Take the pod name.
2. Replace . with _.
3. Strip the trailing -<lastSegment> (the ReplicaSet hash for Deployments, the StatefulSet ordinal lookalike, etc.).
4. Append -<podNamespace>.

So api-7d4b8-xyz in prod becomes api-7d4b8-prod. Two pods from the same ReplicaSet on the same node will share one podIdentifier. This is a deliberate optimisation, same-ReplicaSet pods have identical labels and therefore identical policy attachments, so they can share the same BPF program(s) and one set of maps. It's also a beautifully sharp edge that you only learn about the hard way: any code that reasons about pod-to-program ownership must treat every live pod that hashes to the same identifier as a "still in use" signal, or it will happily delete a program that another pod is still relying on. (Ask me how I know.²)

For each podIdentifier, NPA produces a small constellation of pinned BPF objects under /sys/fs/bpf/globals/aws/:

/sys/fs/bpf/globals/aws/programs/
  <podIdentifier>_handle_ingress
  <podIdentifier>_handle_egress


/sys/fs/bpf/globals/aws/maps/
  <podIdentifier>_ingress_map
  <podIdentifier>_egress_map
  <podIdentifier>_ingress_pod_state_map
  <podIdentifier>_egress_pod_state_map

  global_aws_conntrack_map     # one per node, shared across all pods
  global_policy_events         # perf ring buffer back to userspace

The two programs are loaded from tc.v4ingress.bpf.o and tc.v4egress.bpf.o (plus v6 variants), verified by the kernel's BPF verifier, and attached to TC ingress and egress on the host-side veth of the pod's network namespace. That last detail is the one I want you to take away from this section, because it answers a lot of "but where exactly does the rule live?" questions:

• It's not iptables. There are no cali- or KUBE-NWPLCY- chains. iptables -L will tell you nothing useful.

• It's not a cgroup-level hook. Two containers in the same pod (same network namespace, same veth) get the same enforcement; that's correct, because NetworkPolicy is pod-scoped.

• It's not on the pod-side of the veth, it's on the host-side. Which means the pod can't escape it by playing games inside its own netns, and tc utilities run from the host see it directly.

You can confirm any of this on a real node:

❯ ls /sys/fs/bpf/globals/aws/programs/ | head
api-7d4b8-prod_handle_egress
api-7d4b8-prod_handle_ingress
frontend-9c2d3-prod_handle_egress
frontend-9c2d3-prod_handle_ingress

And you can use bpftool to interact with those programs:

❯ bpftool prog show pinned /sys/fs/bpf/globals/aws/programs/api-7d4b8-prod_handle_ingress
123: sched_cls  name handle_ingress  tag a1b2c3d4e5f6
        loaded_at 2026-05-08T17:42:11+0000  uid 0
        xlated 2104B  jited 1421B  memlock 4096B  map_ids 456,457,458

The map_ids line is the breadcrumb to the policy data. bpftool map dump id 456 will print the actual permitted CIDR-port-protocol entries for that pod's ingress. That is your NetworkPolicy, made byte-shaped.

Stage 4: A packet shows up

A frontend pod opens a TCP connection to 10.0.5.7:8080, the IP of an api pod. Walk the packet through:

1. The packet leaves the frontend container's veth and crosses into the host's network namespace via the host-side veth.

2. TC egress on the frontend host-veth fires frontend-...-prod_handle_egress. The program reads the SKB metadata, builds a 5-tuple (src IP, dst IP, src port, dst port, protocol), and:

   • Looks up global_aws_conntrack_map keyed by 5-tuple. If this is an established connection, it's a hit, the timestamps get bumped, and the packet is permitted. Done. Constant-time.

   • If miss, it looks up frontend-...-prod_egress_map keyed by destination CIDR + port + protocol. Match → permit, also insert into conntrack so the return path is free. No match → drop, emit a perf event into global_policy_events so userspace can log it.

3. The (permitted) packet is forwarded by the host's normal routing and the VPC CNI's ENI plumbing to the destination pod's host-veth.

4. TC ingress on the api host-veth fires api-...-prod_handle_ingress. Same dance: conntrack lookup first, policy map lookup second, drop or permit.

5. The return packet (api → frontend) comes back, hits TC egress on api, and now the conntrack entry from step 2 short-circuits the whole policy lookup. The "stateful" in stateful firewall is, mechanically, that one map lookup.

If you've ever wondered why dropped NetworkPolicy packets don't show up in iptables -nvL, this is why, they were never in iptables. They're in BPF maps. The way to see drops is the perf events stream:

❯ kubectl exec -n kube-system aws-node-xxxxx -c aws-network-policy-agent -- \
    aws-eks-na-cli ebpf dump-policy-events

...or, if you have it, the agent's structured logs.

The whole packet path, TC egress, conntrack, policy lookup, network forward, TC ingress, conntrack, policy lookup, is on the order of microseconds. The expensive part of NetworkPolicy is everything that happened in stages 1–3, which got us here in the first place.

Stage 5: The pod dies, and the policy has to die with it

This is the stage I've spent the most time in over the last few weeks, so I have to resist the urge to write five thousand words on it alone. The short version: cleanup is harder than setup, and the unhappy paths are where dataplanes go to die.

The happy path is simple. The pod is deleted, kubelet runs CNI DEL, the CNI plugin issues a gRPC DeletePodNp() to NPA on 127.0.0.1:50052, the agent detaches the BPF programs, releases its FDs, and unpins the files. If this was the last pod referencing that podIdentifier, the kernel reclaims the program and maps; if not, the agent decrements a refcount and waits.

The unhappy paths look like any of the following:

• The agent OOMs while it's halfway through DeletePodNp().
• The CNI plugin's gRPC call times out after two seconds and soft-fails.
• The node reboots before the agent finishes.
• kubelet skips CNI DEL entirely on certain abnormal pod terminations (this one I had to learn by reading kubelet source).
• The agent restarts, reads the existing pin files via recoverBPFState(), but doesn't fully repopulate its in-memory ProgFD reverse-map, so its own delete RPC silently no-ops on anything it didn't recover correctly.

That last one is a real bug, fixed forward -partially- in NPA v1.3.4, but only forward. On v1.2.1, every one of those scenarios drops a pinned BPF program and four maps on disk, with the kernel still holding the FDs and the memory. On a long-lived node, that's a slow leak. On a long-lived fleet of long-lived nodes, it's a real outage waiting for a quiet weekend. (We caught it right when it started causing problems; it's the kind of thing that puts you off your tea.)

The problem is amplified if your clusters are running a high number of pods that match the selection criteria for your network policy, and it is amplified even more if your workload has a high churn rate.

The bigger point is that any control loop that drives a kernel-level dataplane has the same problem in the same shape: the create path and the delete path are not symmetric, and the delete path runs in the worst conditions, during termination, during failure, during reboot. If you're building this sort of agent, write the cleanup tests first.

A short word on Calico and Cilium

If you're not on EKS-with-VPC-CNI, your dataplane is almost certainly Calico or Cilium, and the answer to "what happens when..." diverges at Stage 3.

• Calico, default mode: same controller pattern, but the dataplane is iptables. Look for chains prefixed cali- in iptables-save -t filter. Easier to inspect with familiar tools, harder to reason about at scale, and every rule update is a non-atomic iptables-restore.

• Calico, eBPF dataplane: closer to NPA in spirit. TC programs, BPF maps, similar shape.

• Cilium: the most architecturally different of the three. Cilium translates labels into a numeric identity at the controller layer, then tags packets with that identity, and the dataplane does identity-to-identity policy lookups instead of IP-to-IP. It scales better in clusters with high pod churn (because identities are stable while IPs are not), and it gets you L7 policy almost for free.

All three answer the same question — should I drop or permit this packet?, with the same overall recipe:

API → control loop → resolved CR or in-process state → node-local agent → kernel hook

The interesting differences live in the last two letters: where exactly do bytes get inspected, and what is the lookup key.

Putting it back together

So, what actually happened when you ran kubectl apply six pages ago?

1. Your YAML became JSON, was authenticated and authorised, ran a gauntlet of admission webhooks, was schema-validated, and committed to etcd.

2. The network-policy controller's watch fired. It resolved your selectors into concrete pods, sliced the result by node, and emitted a PolicyEndpoint per affected node.

3. NPA on each affected node saw the PolicyEndpoint, computed a podIdentifier for the targeted pods, and produced two BPF programs and four BPF maps per identifier, pinned under /sys/fs/bpf/globals/aws/.

4. The programs got attached, by the kernel's BPF verifier and TC subsystem, to the host-side veth of each pod's netns at ingress and egress.

5. The next packet through that veth got 5-tuple-extracted, conntrack-checked, policy-map-checked, and either permitted (with a conntrack insert) or dropped (with a perf event).

6. When the pods die, the whole thing has to unwind in reverse, and the delete path runs in the worst conditions, which is where dataplane bugs live.

Six layers, all of them necessary, any one of them able to fail quietly.

The pretty thing about NetworkPolicy is also the trap: you write a YAML that reads like a firewall rule, and the system makes that abstraction look seamless. But the rule isn't a rule until a TC program woke up forty milliseconds later on a worker node you've never SSH'd into, and pulled four bytes out of an SKB, and looked up a CIDR in an LPM trie. That's where the policy actually lives.

Next time you kubectl apply one, picture the verdict happening down there.

Happy enforcing.
